Waste incineration facility

This incineration facility is designed by experienced specialists.
These specialists design the facility according to the requirement of customers until the overall plan is accepted by customers.

COMBUSTOR^® with more mordernized method of the better waste incineration - S^LOC
Michaelis has developed the incineration procedures by prominent leaders from the traditional method. We call these procedures as the SLOC which means the "Slowed-down Combustion".
The SLOC is the logical improvement and development utilized in the whole procedures of the COMBUSTOR^®

It's the alternative plan for the whole procedures of the pyrolysis. The impressive results can be found out from its operation for a few years. The utility of the SLOC can be achieved from the design of simple blast furnace and automatic control based on its better combustion and lower radiation as well as its utility lasts constantly.

The theory is simpleness itself.
The procedure of combustion has been decreasing by itself since there is a big change in combustion chamber, minimum amount of oxygen combustible materials is reached through the natural infiltration, disintegration by the SLOC process excluding the important air left after being used in traditional method, reinforced drawing, and short period of the heat generation.

The SLOC process also has other important characteristic. The air jet ube fixed in open state between combustion chamber and the secondary chamber guarantees the strong & balanced mixture between fuel fas having requrired air for the combustion. In order to keep the temperature of the secondary combustion chamber under 850 degrees Celsius, the perfect combustion is made. When both the generation by temperature and electrical control is performed in afterburner, small quantity of energy should be added after the small generation of heat.

Addition : COMBUSTOR^® are equipped with the combined dust catcher and gas fan.
This makes them being independent in limited place like chimney. In addition, in order to prevent the increase of dust generated by friction, it elminates the dust generated in the middle of process and during the re-charge without malfunction.

Merits and features

- Simple design of the bursting furnace & automatic control
- Time set-up up to 2-hour interval according to the volume and density of wastes
- Operated regardless of the maximum amount of plastic materials out of wastes.
- Re-charge without malfunction
- Automatic operation make it possible to reduce the labour expenses.
- It removes the dust generated in the middle of the operation regardless of the operating time.
- Under the special and limited value, lower torpedo matters at maximum.
Reference : In accordance with all standards specified in Technical Committee(air), VDI(German Engineer's Association), Quickline 2301 과 DIN(German Industrial Standards) 58990
VDMA(Association of German Machine Makers) guide line 24203.

In case that these condistions are satisfied according to the region, the heat can be utilized in various methods.

Combustion ratio of applied model

The table above refer to the combustion ratio containing the net calorie value, 12560kgJ/kg and a pile of density of wastes.

Utilizing the combustion facility & heat

Absolutely, the heating gas is available generated by the secondary burner and combustor facility for the production of warm water and air.
It's enough guarantee the combustion for 4 hours by connecting the regional water rotation system without any difficulties in the event of the production of warm water and continuous supplying of water.The warm-water guarantee system has been developed from the maintenance. And the problem decreasing the rotating temperature can be solved by simple method according to the recovery of energy. During the combustion, the overall combustion system is built up excluding its dust catcher of dust generated by fuel, and gas fan in steel structure. In fact, it's designed throug two reasons. The flow of rotating materials is reverse against that of fuel with this system. It's the heat absorption depending on the ratio of rotation and length of dust, fuel, and gas. Various types of retrograded facilities, boiler using waste, heat convertor, and humidifier will be installed as demanded.
